Hotel Fire Rated Door Supply Project

Home Project Saudi Arabia Hotel Fire Rated Door Supply Project
date
Year
2024
address
Venue
Riyadh, Saudi Arabia

Client

Saudi Luxury Real Estate Developer

Saudi Arabia Hotel Fire Rated Door Supply Project

Sofitel Makkah Sofitel Jabal Omar Makkah
Qi An Door supported a hotel construction project in Saudi Arabia with a full package of fire rated door products, engineering drawing support, and export delivery. Working from the project's Door Schedule and engineering drawings, our team provided fire rated wooden doors and steel fire doors manufactured to UL and BS 476 fire performance standards, matched to the specification requirements of a hospitality building.

This case study outlines the project requirements, the engineering communication process, and the manufacturing and quality control capability behind the delivered door package.
Project Snapshot
Item
Description
Project Name
Saudi Arabia Hotel Fire Door Supply Project
Location
Saudi Arabia, Middle East
Building Type
Hotel / Hospitality Building
Application
Guestroom Doors, Corridor Doors, Service Area Doors
Products Supplied
Fire Rated Wooden Doors, Steel Fire Doors
Service
Technical Communication, CAD Drawing Support, Customized Manufacturing, Quality Inspection, Export Delivery
Standards
UL, BS 476, ISO 9001

Project Background & Requirements

Hotel buildings present fire protection requirements that differ from residential or general commercial construction. Guestroom corridors function as primary escape routes, and each guestroom door acts as a compartmentation barrier that must hold back fire and smoke long enough for safe evacuation. Because hotels combine high occupant density, overnight sleeping occupancy, and complex corridor layouts, fire rated doors are treated as a core life-safety component rather than a finishing item.

Based on this, the project specification set out three core requirements:

Fire Safety Requirements — Doors tested and certified to internationally recognized standards, with fire resistance performance suitable for guestroom and corridor compartmentation, and certification traceability as a firm project requirement.
Customized Door Specifications — Door sizes, core construction, finish, and hardware preparation matched to the project's Door Schedule and architectural drawings, rather than a fixed catalog size range.
International Project Communication — Technical communication bridging time zone, drawing format, and terminology differences between the project's Door Schedule/BOQ documentation and Qi An's production drawings, with revision cycles managed to avoid delays.
Qi An Door Solution
Qi An's engineering team reviewed the project's Door Schedule and architectural drawings and produced corresponding CAD shop drawings for each door type, covering leaf dimensions, frame profiles, hardware locations, and fire rating labeling requirements — allowing specifications to be confirmed before production.

Based on the confirmed drawings, doors were manufactured to order, covering the leaf core, facing material, frame, and fire-rated door core construction required for the specified fire resistance rating, following the confirmed drawing package door-by-door to match the variation across the Door Schedule.

Doors underwent in-process and pre-shipment quality inspection covering dimensional accuracy, core density and construction, surface finish, and hardware preparation, in line with Qi An's ISO 9001 quality management procedures.

Finally, doors were packaged for export shipment with protective packaging suited to sea freight, with export documentation prepared to support customs clearance at destination.

Products & Technical Specifications

Door Type
Fire Rating
Standard
Application
Customization
Fire Rated Wooden Door
60 / 90 minutes
UL, EN 1634, BS 476
Hotel guestrooms, corridors and interior areas

Designed for hospitality buildings where both fire safety performance and aesthetic appearance are required. Suitable for guestroom entrances, corridor areas and interior applications.
Customized according to Door Schedule and architectural drawings

• Door dimensions
• Surface finish
• Door core structure
• Hardware preparation
• Fire rating requirements
Steel Fire Door
60 / 90 / 120 minutes
UL, EN 1634, BS 476
Service areas, stairwells, technical rooms and back-of-house areas

Suitable for areas requiring higher durability, fire resistance performance and long-term operational reliability.
Manufactured based on project specifications

• Door leaf and frame dimensions
• Frame profile
• Steel thickness
• Door core construction
• Hardware preparation

Technical Features

FeatureDescription
Fire Resistance PerformanceDesigned to provide fire compartmentation and help delay the spread of fire and smoke, supporting safer evacuation in hospitality and commercial buildings.
Project-Based CustomizationEach door is manufactured according to approved Door Schedule, BOQ and CAD drawings instead of standard catalog sizes, ensuring compatibility with project requirements.
Engineering CompatibilitySupports customized door dimensions, finishes, hardware configurations and installation requirements for international construction projects.
Quality ControlProducts undergo inspection during manufacturing and before shipment, including dimensional accuracy, construction quality, surface finish and hardware preparation according to Qi An Door’s ISO 9001 quality management procedures.
87.1美标钢质单开防火门120分钟J231114001-4R1(麒安)
 Our Advantages

Why Choose Us

Reliable Fire Door Solutions for Hotel Projects


With 20+ years of fire door manufacturing experience, Qi An Door provides customized fire rated wooden doors and steel fire doors for international hotel and construction projects. Our engineering team supports BOQ review, CAD drawings, customized production and export delivery to ensure every door meets project requirements.

Engineering, Customization & Quality Assurance


We provide full technical support from BOQ and drawing review to production confirmation, and manufacture doors strictly according to project specifications including size, fire rating, finish and hardware. All products comply with UL, EN 1634, BS 476, AS 1530 and ISO 9001 standards, supported by our own factory in Guangdong for stable production and global delivery.
